Thickness 14Ga
Height H 1 5/8"(in), 41.2(mm)
Weight 1.34(Lbs./Ft.), 0.61(kg/Ft), 2.0(kg/m)

Areas of Section 0.38 / 2.45 sq. in./cm²
Moment of Inertia(I) 0.13 / 5.24 in.⁴ / cm⁴
Section Modulus(S) 0.16 / 2.59 in.⁴ / cm⁴
Radius of Gyration(r) 0.54 / 1.39 in. /cm
Moment of Inertia(I) 0.18 / 7.32 in.⁴ / cm⁴
Section Modulus(S) 0.21 / 3.55 in.³ / cm³
Radius of Gyration(r) 0.64 / 1.64 in. / cm

YP (N/inch2) 0.384
TS (N/inch2) 0.555
EL (%) 45

Thickness 14Ga
Height H 13/16"(in), 20.4(mm)
Weight 0.93(Lbs./Ft.), 0.42(kg/Ft), 1.39(kg/m)

Areas of Section 0.26 / 1.66 sq. in./cm²
Moment of Inertia(I) 0.024 / 0.98 in.⁴ / cm⁴
Section Modulus(S) 0.058 / 0.97 in.⁴ / cm⁴
Radius of Gyration(r) 0.29 / 0.73 in. /cm
Moment of Inertia(I) 0.11 / 4.43 in.⁴ / cm⁴
Section Modulus(S) 0.13 / 2.15 in.³ / cm³
Radius of Gyration(r) 0.61 / 1.55 in. / cm

YP (N/inch2) 0.384
TS (N/inch2) 0.555
EL (%) 45
